Main Stream3200 × 1800@(1–20 fps)/2688 × 1520@(1–25/30 fps)
Sub Stream704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
Smart CodecSmart H.265+; Smart H.264+
Video Frame RateMain stream: 3200 × 1800@(1–20 fps)/2688 × 1520@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability2 streams
Bit Rate ControlVBR;CBR
Video Bit RateH.264: 32 kbps–8192 kbps; H.265: 12 kbps–8192 kbps
InteroperabilityONVIF (Profile S & Profile T); CGI
APIYes
User/Host20 (Total bandwidth: 48 M)
ClientiOS;Android
Web BrowserIE; Chrome; Firefox
AppSmart PSS Lite; DSS; DMSS; DoLynk Care
OthersCyber Security: Video encryption;Configuration encryption;Digest;WSSE;Account lockout;Security logs;Generation and importing of X.509 certification;HTTPS;Trusted boot;Trusted execution;Trusted upgrade
Interface
Network InterfaceRJ-45 (10/100 Base-T)
Alarm
General AlarmNetwork disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human); security exceptio
Environment
Operating Temperature–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity≤95%(RH), non-condensing
Storage Temperature–40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity≤95%(RH), non-condensing
Water ProtectionIP67
Power
Power Supply12 VDC/PoE (802.3af)
PoE Standard802.3af
Power ConsumptionBasic: 2 W (12 VDC), 2.9 W (PoE); Max. : 4 W (12 VDC); 5.3 W (PoE) (H.265 + intelligence on+ DWDR + illuminator intensity)
Physical Information
Casing MaterialMetal
Dimension85.6 mm × Φ94.0 mm (3.37" × Φ3.70")
WeightNet Weight: 0.34 kg (0.75 lb) Gross Weight: 0.45 kg (0.99 lb
