Field of View2.8 mm: H: 110°; V: 58°; D: 132° 3.6 mm: H: 91°; V: 46°; D: 110°
Iris TypeFixed
Close Focus Distance2.8 mm: 1.1 m (3.61 ft) 3.6 mm: 1.7 m (5.58 ft)
DORI Distance2.8 mm: 63.6 m ( 208.66 ft), 25.4 m( 93.33 ft), 12.7 m( 41.67 ft), 6.4m( 21.00 ft) 3.6 mm : 85.4 m( 280.18 ft), 34.2 m( 112.20 ft), 17.1 m( 56.10 ft), 8.5 m( 27.89 ft) DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Illuminator
IR LEDs1 (Multi-core (IR + warm) light)
IR DistanceUp to 30 m (98.43 ft) (IR) Up to 30 m (98.43 ft) (Warm light)
Illuminator ControlAuto;Manual
Video
Video CompressionH.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Main Stream3200 × 1800@(1–20 fps)/2688 × 1520@(1–25/30 fps)
Sub Stream704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
Smart CodecSmart H.265+; Smart H.264+
Video Frame RateMain stream: 3200 × 1800@(1–20 fps)/2688 × 1520@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability2 streams
Bit Rate ControlVBR;CBR
Video Bit RateH.264: 32 kbps–8192 kbps; H.265: 12 kbps–8192 kbps
InteroperabilityONVIF (Profile S & Profile T); CGI
APIYes
User/Host20 (Total bandwidth: 48 M)
ClientiOS;Android
Web BrowserIE; Chrome; Firefox
AppSmart PSS Lite; DSS; DMSS; DoLynk Care
OthersCyber Security: Video encryption;Configuration encryption;Digest;WSSE;Account lockout;Security logs;Generation and importing of X.509 certification;HTTPS;Trusted boot;Trusted execution;Trusted upgrade
Interface
Network InterfaceRJ-45 (10/100 Base-T)
Alarm
General AlarmNetwork disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human); security exception
Environment
Operating Temperature–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity≤95%(RH), non-condensing
Storage Temperature–40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity≤95%(RH), non-condensing
Water ProtectionIP67
Power
Power Supply12 VDC/PoE (802.3af)
PoE Standard802.3af
Power ConsumptionBasic: 2 W (12 VDC), 2.9 W (PoE); Max.: 4 W (12 VDC), 5.3 W (PoE) (H.265 + intelligence on+ DWDR + illuminator intensity)
Physical Information
Casing MaterialMetal
Dimension173.3 mm × 70.0 mm × 70.0 mm (6.82" × 2.76" × 2.76") (L × W × H)
WeightNet Weight: 0.44 kg (0.97 lb) Gross Weight: 0.55 kg (1.21 lb)
