Record RateMain stream: the 1st channel 1080N/720p@(1 fps–25/30 fps), others 1080N/720p@(1 fps–15 fps); 960H/D1/CIF@(1 fps–25/30 fps) Sub stream: CIF@(1 fps–7 fps)
Bit Rate32 kbps–4096 kbps
Record ModeGeneral; alarm; motion detection
Video Detection And Alarm
Alarm InputMotion detection; HDCVI alarm; camera external alarm; network alarm; PIR alarm Intelligent Alarm: SMD Plus
Playback And Backup
Sync Playback1/4/9/16
Playback FunctionPlay; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom
Backup ModeUSB device and network
Third Party Support
Third Party SupportDahua, Arecont Vision, AXIS; Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Network
Interface1 (10/100 Mbps Ethernet port, RJ-45)
Network FunctionHTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)
Storage
Internal HDD1 SATA port, up to 16 TB.
eSATAN/A
Auxiliary Interface
USB2 (2 rear USB 2.0 ports)
RS232N/A
RS485N/A
Power
Power SupplyDC 12V/2A
Power Consumption< 10W
Component Environment
Operational Conditions-10°C to +45°C (+14°F to +113°F), 10%–90% (RH)
Storage Conditions-20°C to +70°C (-4°F to +158°F), 0%–90% (RH)
Construction
Dimensions260.0 mm × 231.6 mm × 47.6 mm (10.24" × 9.12" × 1.87") (W × D × H)
