Image Sensor1/3″ Progressive Scan CMOS
Effective Pixels4MP+4MP
Max. Resolution2K+ (2560 × 1440)
Frame RateSelf-adaptive during network transmission
LensTop Lens: 2.8mm @ F1.6, Field of view : Diagonal 110°, Horizontal 96°, Vertical 54° Bottom Lens: 6mm @ F1.6, Field of view : Diagonal 60°, Horizontal 52°, Vertical 28°
Pan & TiltTop Lens: Pan: 220°, Tilt: 10° (manual adjustment for vertical angle ) Bottom Lens: Pan: 324°, Tilt: 90°
IR Distance30 m (98 ft)
Field of ViewDiagonal 110°, Horizontal 96°, Vertical 54°
Min. Illumination0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories)
Video CompressionH.265 / H.264
Bit RateQuad HD; Full HD; Standard adaptive bit rate
DNR3D DNR
WDRDigital WDR
Smart AlarmMotion Detection, Human Detection, Human Tracking, Noise Detection, Auto Patrol
ButtonReset Button
Storage TypeMicro SD card slot (Max. 512GB)
OthersWeatherproof Design Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark
