Data Rate2402 Mbps (5 GHz) + 574 Mbps (2.4 GHz)
Antenna4× 5 dBi Fixed Omni-Directional Antennas
ButtonReset/WPS Button
Frequency2.4 GHz < 20dBm (EIRP) 5 GHz < 23dBm (band1、 band2) 5 GHz < 30dBm (band3)
WirelessEnable/Disable Wireless Radio, WMM
Interface1× Gigabit WAN Port + 3× Gigabit LAN Ports
Network StandardCompatible with 802.11ax/ac/a/b/g/n Wi-Fi standards
EncryptionWEP, WPA / WPA2-Personal, WPA2 / WPA3-Personal
PortsNetwork Services Enabled by Default Web Server Manage and configure device through web (HTTP/HTTPS) Port: 80/443; Protocol: TCP DHCP Server IP address assignment (DHCP) Port: 67; Protocol: UDP DNS Port: 53; Protocol: TCP & UDP App management Manage and configure device through app Port: 20001; Protocol: TCP Port: 20002; Protocol: UDP
OthersReception Sensitivity 11g 6Mbps: -97dBm 11g 54Mbps: -79dBm 11n HT40 MCS7:-74dBm 11n HT20 MCS7:-77dBm 11a 6Mbps: -97dBm 11a 54Mbps: -79dBm 11ac VHT20 MCS8:-75dBm 11ac VHT40 MCS9:-71dBm 11ac VHT80 MCS9:-67dBm 11ax VHT20 MCS11:-67dBm 11ax VHT40 MCS11:-64dBm 11ax VHT80 MCS11:-61dBm
Operating System SupportWAN Type Dynamic IP/Static IP/PPPoE/L2TP/PPTP Management Access Control Local Management Remote Management NAT Forwarding Port Forwarding, Port Triggering, UPnP, DMZ Firewall Security SPI Firewall, IP and MAC Address Binding Guest Network 2.4 GHz Guest Network, 5 GHz Guest Network DHCP Server, DHCP Client List VPN Server OpenVPN, PPTP supported
