InterfaceArchitecture ARM 32bit CPU AL21400 CPU core count 4 License level 5 Size of RAM 1 GB Storage size 512 MB Storage type NAND
PortsPoE-out ports Ether10 SFP+ ports 1 ( RJ45)
OthersPCB temperature monitor Yes Voltage Monitor Yes Tested ambient temperature -40°C to 70°C
Operating System SupportOperating System RouterOS
Power Source
Power ModePoE in Passive PoE PoE in input Voltage 18-57 V PoE out Passive PoE up to 57V PoE-out ports Ether10 Number of DC inputs 2 (DC jack, PoE-IN) DC jack input Voltage 12-57 V Max out per port output (input > 30 V) 400 mA Max out per port output (input < 30 V) 600 mA Max total out (A) 600 mA Max power consumption 33 W Max power consumption without attachments 18 W
