Data RateUp to 300Mbps2.4GHz UP to 867Mbps 5GHz 802.11ac:80MHZ(433Mbps, 867Mbps) 802.11n: 40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps) 20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense) 803.11g: (54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps) 802.11b: (11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps)
Antenna6* external fixed 5dBi antenna
ButtonReset
Frequency2.4-2.4835GHz 5.180-5.825GHZ
WirelessWireless Modes: AP Router, Repeater, Client, Multi-SSID
Interface1*10/100/1000Mbps Auto MDI/MDIX RJ45 WAN port 3*10/100/1000Mbps Auto MDI/MDIX RJ45 LAN port
Network StandardIEEE 802.11b/g/n 2.4GHz IEEE 802.11a/n/ac 5GHz
EncryptionWEP/WPA-PSK/WPA2-PSK/WPA/WPA2-PSK Encryption Wireless MAC Filtering
OthersTransmit Power: 20dBm(MAX) WAN Type: DHCP, Static IP, PPPoE,（Russia PPPoE）, L2TP, PPTP, Bandwidth Control, Access Control, IPTV, Virtual Server, DMZ, VPN Pass-through, Dynamic DNS, Static Routing, Backup & Restore MU-MIMO, beamforming technology. Multi-SSID providing up to 8 additional separate networks for guests and friends Built-in signal power amplifier in chip for higher WiFi coverage Intelligent bandwidth control. Support EASY MESH networking Complete Gigabit ports. Easy setup and support App management conveniently.
