Data Rate2.4GHz: 574Mbps (802.11ax) 5GHz: 2402Mbps (802.11ax)
Antenna4 x 3dBi Internal antenna Per Node
Button1 x Reset Button 1 x MESH Button
FrequencyDual Band (2.4GHz & 5GHz)
Network StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3ab 5GHz: IEEE 802.11ax/ac/n/a 2.4GHz: IEEE 802.11ax/n/b/g
EncryptionWPA3-SAE/WPA2-PSK
Ports3 x 10/100/1000Mbps RJ45 ports
OthersLED Indicator: 1 x Tri-color LED Indicator(Green,Yellow,Red) Basic Functions: Beam Forming, MU-MIMO, AP Steering, Band Steering, OFDMA, 1024-QAM Internet Connection Type: PPPoE, Dynamic IP, Static IP, PPPoE(Russia), PPTP(Russia), L2TP(Russia) Network Protocol: IPv4&IPv6 Operating Mode: Router Mode,AP Mode Parental Control: Client Filter, URL Filter, Time Limit DHCP: DHCP Server, DHCP Client List Virtual Server: Port Forwarding, DMZ Host, UPnP Firewall: Forbid TCP/UDP flood attack VPN: PPTP Server, PPTP/L2TP Client DNS: Support manually setting DNS server Special Features: Ethernet Backhaul, IPv6, IPTV Other Function: Support App and web management, Guest Network, Firmware upgrade online
