Fingerprint Capacity10000
Face Capacity10000
ID Card Capacity50000
Record CapacityLogs Capacity - 300000
Display7" Touch LED Screen
CommunicationTCP/IP x 1, Wiegand (Input or Output) x 1, RS485: ZKTeco RS485 x 1, USB: Type A (USB Drive Only) x 1, Aux Inputs x 1, Electric Lock x 1, Door Sensor x 1, Exit Button x 1, 12V Output x 1
Standard FunctionsADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch, Multiple Authentication Methods, SIP Client (Version 2.0), ONVIF (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A), AC Push and TA Push Protocol Switch, HTTPs / SSH Backend Access, T9 Keyboard (Input)
InterfaceRS485 (RS485 Card Reader / Biometric Reader)
OthersAlgorithm Version ZKFace V4.0, ZKFingerprint V13.0 (Standard) / V10.0 (Optional) SDL/Software Software: ZKBio CVAccess / ZKBioTime, Mobile App.: ZKBio Zlink, Cloud Service: ZKBio Zlink Authentication Fingerprint / Face / Card / Password (Virtual Keypad) Operating System Linux Camera Details WDR Binocular Camera 1MP
