Image Sensor1/3 Progressive Scan CMOS sensor
Frame RateFixed Lens：1-25fps (2304 × 1296 1-18fps), Default 18fps PT Lens：1-25fps (2304 × 1296 1-18fps), Default 18fps
LensFixed Lens：4mm PT Lens：6mm
Pan & Tilt0°to 260°
IR DistanceUp to 30 m/100 ft (depending on environment)
Field of ViewFixed Lens： Horizontal FOV: 82.3°, Vertical FOV: 44.7°, Diagonal FOV: 97.4° PT Lens： Horizontal FOV: 51.8°, Vertical FOV: 28.2°, Diagonal FOV: 60.4°
Video CompressionFixed Lens：H.265, H.264 PT Lens：H.265, H.264
Bit RateFixed Lens：512kbps -- 4096kbps PT Lens：512kbps -- 4096kbps
Audio Input / OutputTwo-way Audio, Voice Input
DNR3D DNR
WDRDWDR, BLC, HLC
Smart AlarmSmart Detection Both fixed lens and PT lens are supported motion detection, human detection, vehicle detection, line crossing Detection, intrusion detection Smart Linkage Sound&light Alert, Dual-lens Linkage Tracking
ButtonReset Button
Storage TypeBuilt-in Micro SD Card Slot, Up to 512 GB
CertificationsCE, RoHS, FCC, RCM, UKCA
OthersIP65
